Bison 160 Jaw Crusher (Hybrid)

Download Brochure Technical Specifcations Talk to an Expert

Overview

The EvoQuip Bison 160 Hybrid hook-lift jaw crusher represents a new milestone for EvoQuip. It is an ideal jaw crusher for waste contractors who can utilize existing hook-lift vehicles to either bring material to depot for processing or alternatively bring the jaw crusher to the waste on site – turning waste into profit whilst providing excellent productivity and fuel efficiency.

features

Jaw Crusher
Compact Design for ease of transportation
High Output Potential up to 100 tph / 110 US tph
Backed with OPS's Aftermarket Services and support

TEchnical specifications

2.0m3 (2.6yd3) Hopper capacity
Integrated pre-screen as standard

700mm x 500mm (28”x20”) Jaw inlet
CSS range: 30mm to 110mm (1.2” to 4.3”)
Reverse drive function

Gen set incorporating Leroy alternator (88KVA standby)
CAT C4.4 70kW Constant Speed LRC c/w 88kVA Generator
CAT C4.4 70kW Constant Speed T3a c/w 88kVA Generator
CAT C4.4 70kW Constant Speed T4 c/w 88kVA Generator
CAT C3.6 70kW Constant Speed eu5 c/w 88kVA Generator

4.88m X 1.52m (16’ X 5’) single deck after screen c/w
40mm mesh as standard unless otherwise stated
500mm (20”) wide belt transfer conveyor
500mm (20”) wide belt hydraulic folding re-circulating conveyor able to slew for stockpiling oversize material
1.4m (55”) wide belt fines conveyor
Rapid detach after screen system for flexibility.
