Bison 35 Jaw Crusher


Overview


The Bison 120 is a compact jaw crusher that has been specifically designed for operators for whom versatility, manoeuvrability and transportability are of key importance. It is compact enough to fit inside a container for transport and is suited to medium sized C&D recycling applications.


The Bison 120 features a ‘680mm x 400mm’ single toggle Jaw Crusher that can be adjusted hydraulically using the remote control which comes as standard with the machine. The Jaw is driven hydraulically allowing the customer the ability to reverse the Crusher to clear a blockage as well as being able to run in reverse permanently for sticky applications such as asphalt. The ability to adjust the jaw setting and operate the plant fully from the remote control allows for a fast and simple set up for the customer. With its intuitive operation, quick set-up times, compact size and ease of transport the Bison 120 the ideal solution for all small to medium sized operators.

features


  • Jaw Crusher
  • Compact Design for ease of transportation
  • Backed with OPS's Aftermarket Services and support
  • This is paragraph text. Click it or hit the Manage Text button to change the font, color, size, format, and more.
  • This is paragraph text. Click it or hit the Manage Text button to change the font, color, size, format, and more.
  • This is paragraph text. Click it or hit the Manage Text button to change the font, color, size, format, and more.

TEchnical specifications


  • Belt feeder as standard
  • Variable speed

  • 480mm x 250mm (19” x 10”) Jaw Inlet
  • CSS Range: 15mm to 80mm (5/8” to 3-1/4”)
  • Hydraulic Jaw adjustment

  • Tier 3: 21kW / 28.5Hp Isuzu Engine
  • Direct drive
  • Stage V: Kubota V 1505

  • Up to 30tph / 34 US tph

  • 400mm (16”) Wide product conveyor
  • Product conveyor discharge height: 1100mm (3’4”)

  • Remote control as standard

  • Length: 4.45m (14’ 7”)
  • Width: 1.5m (4’ 11”)
  • Height: 2.05m (6’ 9”)
  • Weight: 3,400kgs (7,496lbs)
