Colt 600


Overview


The Colt 600 Compact Scalping Screen has been specifically designed for operators for whom versatility, manoeuvrability and transportability are of key importance. It is small enough to fit inside a container for transport but strong enough to withstand the toughest of applications. The Colt 600 is a compact and aggressive forward facing screen that can work in aggregates, sand and gravel, top soil, construction demolition and recycling applications where site space is at a premium. With the large range of screen media available including bofor bars, finger screens, woven mesh and punch plates it provides the user with a level of versatility that is second to none.

features


  • Screen
  • Compact Design for ease of transportation
  • High Output Potential up to 280 tph / 308 US tph
  • Backed with OPS's Aftermarket Services and support

TEchnical specifications


  • 3m3 (3.9yd3 ) Hopper capacity
  • 1m (40”) Wide
  • Variable speed
  • Maximum feed size: 300mm (12”)

  • 2.34m x 1.17m (8’ x 4’) Double deck screen
  • Wide range of screen media Top Deck
  • Bofor Deck, Fingers, Punch Plate & Mesh
  • Bottom Deck – Mesh & Fingers

  • Tier 3: Deutz D2011 L04I - 36.4kW (48.8 Hp) @ 2300 RPM
  • Tier 4F / Stage lV: Deutz TD2.9L4 – 42kW (56 Hp) @ 1900
  • RPM Stage 5: Deutz TD2.9L4 – 42kW (56 Hp) @ 1900 RPM

  • 650mm (26”) Wide fines conveyor with 2.9m (9’6”) discharge
  • 650mm (26”) Wide midgrade conveyor with 2.8m (9’2”) discharge
  • 1000mm (40”) Wide oversize conveyor with 2.7m (8’10”) discharge
  • Variable speed on midgrade and oversize as standard
  • Ability to convert to 2 way split

  • Length: 10.98m (36’)
  • Width: 2.25m (7’ 5”)
  • Height: 2.55m (8’ 4”)
  • Weight: 12,000kgs (26,455lbs)
