Harrier 750 Screener

Overview

The Harrier 750 is a high capacity Mobile Screening Machine. With its robust construction the Harrier 750 Mobile Screening Machine can withstand the toughest scalping applications while still being versatile enough to perform at a high level in fine screening applications. It really is the perfect multipurpose machine for your site.

features

  • Screen
  • Compact Design for ease of transportation
  • High Output Potential up to 600tph / 660 US tph
  • Backed with OPS's Aftermarket Services and support

TEchnical specifications

  • 4.5m x 2.6m (14’8” x 8’7”) Double deck grid
  • Split level cassettes as standard
  • Standard grid opening – 150mm (6”); 100mm (4”) is optional
  • Standard bottom deck mesh – 60mm (2.4”)

  • Tier 3: Deutz D914 53kW (71Hp) @2300rpm
  • Tier 4 / Stage lV: Cat C3.4 - 55kW (74Hp) @ 1800rpm)
  • Stage 5: Cat C2.2 – 55Kw (74Hp) @ 2300rpm

  • 1200mm (48”) Wide product conveyor with discharge height of 3.4m (11’2”) Hydraulically folding for transport
  • Twin drive as standard

  • Length: 9.43m (31’)
  • Width: 2.82m (9’ 3”)
  • Height: 3.2m (10’ 6”)
  • Weight: 3,400kgs (7,496lbs)
